High Sieving Accurately Tumbler Swing Vibrating Screen For Powder
Technical Parameter
Application
Chemical, food and spices, plastics, mining, medicine, wood and plywood, metallurgy, rubber, fodder, fertilizer, sugar, salt, renewable industry.
Tumbler screen is an efficient sieving machine which is designed to meet the large output, high-density sieving of the manufacturers. The simplest sieving method is using your hands with the staring of your eyes.
Technical Parameter
| Model | YBS-600 | YBS-1000 | YBS-1200 | YBS-1600 | YBS-2000 | YBS-2400 | YBS-2600 |
| Diameter(mm) | 600 | 1000 | 1200 | 1600 | 2000 | 2400 | 2600 |
| Sieving area(m² ) | 0.29 | 0.71 | 1.11 | 1.83 | 2.62 | 3.63 | 5.31 |
| Spatial requirement | 0.4 | 1.2 | 1.6 | 2.5 | 3.6 | 5.2 | 6.8 |
| Max sieve layer(s) | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| Power Consumption(Kw) | 0.25 | 1.5 | 2.2 | 2.2 | 2.2 | 5.5 | 5.5 |
| Filter accessories | 2 layers | 2 layers | 2 layers | 1 layer | 1 layer | 1 layer | 1 layer |
Application
Chemical, food and spices, plastics, mining, medicine, wood and plywood, metallurgy, rubber, fodder, fertilizer, sugar, salt, renewable industry.
